Massey Ferguson 1035 DI vs 1035 DI Super Plus: Which Model Is Different?

Massey Ferguson 1035 DI Specifications

The Massey Ferguson 1035 DI is a 35 HP utility tractor designed for small to medium farming operations with basic hydraulic systems and mechanical controls. It features a single-cylinder diesel engine capable of 2500 RPM with 2 hydraulic outlets for implement operation.

Engine Specifications

• Engine Type: Single-cylinder, 4-stroke diesel engine
• Power Output: 35 HP (26 kW) at 2500 RPM
• Displacement: 2210 cc
• Torque: 95 Nm at 1600 RPM
• Fuel Tank Capacity: 45 liters
• Cooling System: Liquid-cooled radiator with thermostat

Transmission & Hydraulics

• Transmission Type: Mechanical synchromesh (8 forward, 2 reverse)
• Max Speed: 24 km/h (forward)
• Turning Radius: 3.2 meters
• Hydraulic System: 2 single-acting cylinders
• Hydraulic Pump Capacity: 25 liters/minute
• Hitch Category: Cat-I with 1500 kg lift capacity

Chassis & Dimensions

• Overall Length: 3650 mm
• Overall Width: 1800 mm
• Overall Height: 2100 mm
• Wheelbase: 2200 mm
• Ground Clearance: 450 mm
• Dry Weight: 1850 kg

Massey Ferguson 1035 DI Super Plus Specifications

The Massey Ferguson 1035 DI Super Plus is the advanced variant of the 1035 DI with enhanced hydraulic capacity, dual-acting cylinders, and improved comfort features for extended working hours. It maintains the same 35 HP engine but adds modern conveniences like power steering and upgraded seating.

Engine Specifications (Super Plus Model)

• Engine Type: Single-cylinder, 4-stroke diesel engine (identical to base model)
• Power Output: 35 HP (26 kW) at 2500 RPM
• Displacement: 2210 cc
• Torque: 95 Nm at 1600 RPM
• Fuel Tank Capacity: 50 liters (+5L advantage over base model)
• Cooling System: Enhanced liquid-cooled radiator

Enhanced Transmission & Hydraulics

• Transmission Type: Mechanical synchromesh with power shuttle (8 forward, 2 reverse)
• Max Speed: 24 km/h (same as base model)
• Power Steering: Yes (hydraulic-assisted, absent in base model)
• Hydraulic System: 4 double-acting cylinders (upgraded from 2 single-acting)
• Hydraulic Pump Capacity: 45 liters/minute (upgraded from 25 L/min)
• Hitch Category: Cat-II with 2000 kg lift capacity (vs Cat-I 1500 kg)
• Remote Hydraulic Outlets: 2 additional remote lines for precision control

Advanced Comfort & Controls

• Steering Type: Power-assisted hydraulic steering
• Seat: Ergonomic suspension seat with lumbar support
• Cabin Protection: Canopy with weather shield
• Headlight System: Dual LED headlights with adjustable angles
• Engine Immobilizer: Electronic safety kill switch

Chassis & Dimensions (Super Plus)

• Overall Length: 3750 mm (+100mm for extended radiator)
• Overall Width: 1800 mm (same as base model)
• Overall Height: 2150 mm (+50mm for canopy integration)
• Wheelbase: 2250 mm (+50mm for better weight distribution)
• Ground Clearance: 460 mm (+10mm for improved obstacle crossing)
• Dry Weight: 2050 kg (+200 kg for enhanced hydraulic system)

Massey Ferguson 1035 DI vs 1035 DI Super Plus: Key Differences

The primary difference between these models is the hydraulic system capacity and comfort features; the Super Plus offers double-acting cylinders, power steering, and 5 HP additional pump capacity, while the base DI model features manual steering and single-acting cylinders. Both share the same 35 HP engine core.

Feature	1035 DI	1035 DI Super Plus	Advantage
Hydraulic Cylinders	2 single-acting	4 double-acting	Super Plus (better control)
Pump Capacity	25 L/min	45 L/min	Super Plus (80% more power)
Steering Type	Manual (mechanical)	Power-assisted (hydraulic)	Super Plus (reduced fatigue)
Hitch Lifting Capacity	1500 kg (Cat-I)	2000 kg (Cat-II)	Super Plus (33% stronger)
Fuel Tank	45 liters	50 liters	Super Plus (longer range)
Weight	1850 kg	2050 kg	DI model (lighter operation)
Price Range	₹8.5 - 9.2 lakhs	₹10.2 - 11.0 lakhs	DI model (20% cheaper)
Cabin Canopy	Optional add-on	Standard feature	Super Plus (included)
Steering Comfort	Medium effort required	Low effort (power-assisted)	Super Plus (operator comfort)
Implement Compatibility	Cat-I implements	Cat-I & Cat-II implements	Super Plus (versatile)

Massey Ferguson 1035 DI Features

The 1035 DI provides essential farming capabilities with a robust single-cylinder diesel engine, 2-speed transfer case for field work, and category-I hitch for light to medium implements. It's built for reliability in smaller farm operations requiring basic hydraulic functions.

• 35 HP continuous power output for PTO-driven equipment
• 2 hydraulic remote outlets for basic implement control
• Mechanical synchromesh transmission with smooth gear engagement
• Deep cleats agricultural tires designed for traction in wet soil
• Manual wet-disk brakes with good stopping power
• Easily accessible engine maintenance points
• Mechanical throttle control with predictable response

Massey Ferguson 1035 DI Super Plus Features

The Super Plus variant adds operational efficiency features including dual-acting hydraulic circuits, power steering, and extended comfort systems that enable all-day farming without operator fatigue. It's optimized for operations requiring multiple simultaneous implement functions.

Hydraulic Performance Features:

• 45 L/min dual pump circuit for simultaneous implement operation
• 4 double-acting cylinders providing bidirectional control
• 2 remote hydraulic outlets with proportional control valves
• Load-sensing hydraulic system maintaining consistent pressure

Operator Comfort Features:

• Hydraulic power steering requiring minimal manual input
• Suspension seat with shock absorption for bumpy terrain
• Weather-protected canopy with side panels
• Dual LED headlights with 40% higher luminosity than base model
• Electronic ignition system with engine temperature monitoring

Safety & Modern Features:

• Electronic immobilizer preventing unauthorized operation
• Reverse gear warning system with audible alert
• Brake pad wear indicators for preventive maintenance
• Engine protection systems with automatic shutdown at critical temperatures

Massey Ferguson 1035 DI Implements Compatibility

The 1035 DI with Category-I hitch supports a wide range of entry-level agricultural implements including moldboard plows, harrows, cultivators, and light trailers. Maximum implement weight capacity is 1500 kg, suitable for small landholding operations up to 20 acres.

Compatible Implements List:

• Plowing: Single-furrow moldboard plow (45 cm width)
• Soil Preparation: Spring-loaded harrow, heavy cultivator
• Seeding: Manual broadcast seeder, trailing seed drill
• Weeding: Inter-row cultivator with 3 tines
• Cutting: Rotary mower (1.2m cutting width)
• Transport: Tandem trailer with braking system
• PTO Equipment: Chaff cutter, corn sheller, small thresher

Maximum Working Depth: 200mm (limited by single-cylinder power)

Wheel Slip Recommendation: 15-18% for optimal traction during fieldwork

Massey Ferguson 1035 DI Super Plus Implements Compatibility

The Super Plus's enhanced hydraulic system and Cat-II hitch support heavier implements with multiple functions, including dual-furrow plows, rotavators, and boom sprayers. Maximum implement weight capacity increases to 2000 kg, enabling operations on 30+ acre farms.

Advanced Implements Support:

• Plowing: Dual-furrow moldboard plow (80 cm combined width)
• Soil Preparation: Rotavator with adjustable depth control
• Spraying: Boom sprayer with hydraulic height adjustment (600L capacity)
• Harvesting: Reaper-binder, chaff cutter with variable feed
• Fertilizing: Mounted fertilizer spreader with proportional distribution
• Drainage: Laser-guided land leveler for precision grading
• Transport: Heavy-duty tandem trailer (3000 kg capacity)

Enhanced Working Features:

• Proportional control allows fine-tuned implement operation
• Remote hydraulic outlets enable mid-field implement changes
• Load-sensing hydraulics maintain power during deep tillage
• Electronic PTO allows synchronized engagement for safety

Traction Advantages: 18-20% wheel slip for better soil conservation

Massey Ferguson 1035 DI vs Super Plus: Which Model Should You Choose?

Choose the 1035 DI if you operate a small farm (under 20 acres) with light implements and budget constraints; choose the Super Plus if you need simultaneous multi-function implement operation, all-day comfort, or plan farm expansion to 30+ acres.

Choose 1035 DI If You:

• Operate on farms under 20 acres
• Use primarily single-function implements (plow, harrow, or mower)
• Have a budget below ₹9.5 lakhs
• Work 4-6 hours daily
• Prioritize lower fuel consumption and maintenance costs

Choose 1035 DI Super Plus If You:

• Plan to expand farming operations to 30+ acres
• Require simultaneous implement functions (spraying while cultivating)
• Operate 8+ hours daily requiring operator comfort
• Have budget capacity of ₹10.5 lakhs or above
• Need precision control for advanced implements (boom sprayers, rotavators)
• Want comprehensive warranty and modern safety features

Frequently Asked Questions (FAQ)

1. What is the main difference between Massey Ferguson 1035 DI and Super Plus?

 The main difference is the hydraulic system—Super Plus has 4 double-acting cylinders with 45 L/min capacity versus the base model's 2 single-acting cylinders with 25 L/min capacity. Additionally, Super Plus includes power steering and a standard canopy, while the base DI model uses manual steering.

2. Which model has better fuel efficiency?

 The 1035 DI base model is 15-18% more fuel-efficient than Super Plus, consuming approximately 3.2 liters per hour versus 3.8 liters per hour for Super Plus.

3. Can I upgrade from 1035 DI to Super Plus components?

 Partial upgrades are possible but not cost-effective—power steering retrofit costs ₹18,000, hydraulic system upgrade costs ₹25,000, totaling ₹43,000, which is nearly the price difference between models (₹1.8 lakhs)..

4. What is the warranty difference between 1035 DI and Super Plus?

Base 1035 DI includes 2-year/1000-hour warranty covering engine and transmission. Super Plus extends to 3-year/1500-hour comprehensive warranty including hydraulic components and electronic systems.

5. Which model is better for irrigation farming or horticulture?

1035 DI Super Plus is better for irrigation farming due to its superior hydraulic capacity (45 L/min) required for operating lift irrigation and overhead sprinkler systems simultaneously. For horticulture on small plots, the base 1035 DI provides adequate functionality.
