Mahindra YUVRAJ 215 NXT

Key Features

Engine (CC) 863.5 CC
Clutch Type
Gear Type
Drive Type 2WD

Model Overview

The Mahindra YUVRAJ 215 NXT Tractor is a compact 15 HP mini tractor designed for small-scale farms and orchard operations. Powered by a single-cylinder, 864 CC water-cooled engine, it provides reliable performance with a rated RPM of 2300, ensuring efficiency in various agricultural tasks. The Mahindra YUVRAJ 215 NXT Tractor features a 6 forward + 3 reverse gearbox, allowing for versatile speed control, and mechanical steering for easy maneuverability. With a 778 kg hydraulic lifting capacity, it is capable of handling a variety of farming implements, making it a perfect choice for small farm owners seeking reliability and power in a compact form.

Engine

Air Filter Wet type
Max Torque 48Nm
No of Cylinder 1
Drive type 2WD
Cooling System Water-Cooling
PTO HP 11.4 Hp
Engine Rated RPM 2300 rpm
Horse Power (HP) 15
Engine Capacity 863.5 CC
Engine Type DI Engine

Transmission

Reverse Speed (Min-Max) Up to 5.51 km/h
Forward Speed (Min-Max) Up to 25.62 km/h
Brake Type Dry disc brakes
Clutch type Single plate dry clutch
Gear Shift Type Center shift
Gear Box 6 Forward + 3 Reverse
Transmission Type Sliding mesh

Specification

Fuel Tank Capacity 19 L

Dimension and weight

Ground Clearance 245 mm
Tractor width 1690 mm
Overall Length 3730 mm
Wheelbase 1490 mm
Weight 780 kg

Hydraulics

Linkage & Controls 3 Point Linkage
Lifting capacity (in kg) 778 Kg

Assurance

Warranty 1 Years

Others

Electricals 12V, 65 Ah
Accessories Trailer hitch, front tow hook, linkage drawbar
Turning radius with brake 2600 mm
Steering Type Mechanical steering
